Oilfield Tool Equipment

DZ225/5-TG

TJ2-41

DZ225/6-K

DZ315/7.5-K

DZ450/7.5-K

Floor height, m

5

4.5

6

7.5

7.5

Height of rotary beam
above ground, m

3.8

4.8

6.3

6.2

Rotary beam capacity, kN

2250

2200

2250

3150

4500

Setback capacity, kN

1200

1500

1200

1600

2200

Bottom bore, m

4

8.02X8.02

9

9

10

Weight, kg

102000

36800

125100

118300

145800

Note: T-skid mounted    TG-Trailer mounted   K-Piled box mounted

DZ90/4.5-S

DZ225/7.5-S

DZ315/9-S

DZ450/9-S

DZ450/10.5-S

DZ585/10.5-S

Floor height, m

4.5

7.5

9

9

10.5

10.5

Height of rotary beam above ground, m

3.4

6.15

7.69

7.62

9

9

Rotary beam capacity, kN

900

2250

3150

4500

4500

5850

Setback capacity, kN

500

1200

1600

2200

2200

2700

Bottom bore, m

2.9

8.5

8

9

9

9

Weight, kg

28800

131400

165000

190100

197000

212000

Note: S-sling shot

DZ180/6-X

DZ225/6-X

DZ315/9-X

DZ450/10.5-X

DZ675/12-X

DZ900/12-X

Floor height, m

6

6

9

10.5

12

12

Height of rotary beam above ground, m

4.775

4.8

7.7

9.08

10

10

Rotary beam capacity, kN

1800

2250

3150

4500

6750

9000

Setback capacity, kN

3000

1200

1600

2200

3250

4320

Bottom bore, m

1.86

9

9

10

10

10

Weight, kg

47800

124000

154800

147800

245000

265000

Note: X-swing lift
